Description
Model PGS100 is the compact, reliable, essential gauge pressure
transmitter suitable for liquid, gas or steam applications. It is a
straightforward and robust device designed for rapid delivery and easy
installation and use. Thanks to its rugged design offering high
resistance in even the most demanding environments, it is a competitive
solution for most applications, including ones in hazardous areas.
PGS100 - Essential Gauge Pressure Transmitter (Base accuracy 0.25 %) |
| Sensor Range | K | 200 and 4000 kPa (2 and 40 bar, 29 and 580 psi) |
| Maximum working pressure | S9 | Standard by design according to sensor range |
| Diaphragm material | A | AISI 316L ss |
| Fill Fluid | 1 | Silicone oil |
| Process Connection Material | A | AISI 316L ss |
| Process Connection Size | B | 1/2 in - 14 NPT male / 1/4 in - 18 NPT female (adapter compatible) |
| Bolts and Gaskets | Y | None |
| Housing Material / Electrical Connection | S | AISI 316L ss / 1/2 in. -14 NPT female thread (through adapter - supplied loose) |
| Protocol/Output | H | HART / 4 to 20 mA (including Easy Set up) |
| Display | D4 | Backlit glass touch LCD display with 2-button keypad |
| Hazardous Area Certifications | HCM | CSA approvals (USA and Canada) IS (Gas and Dust) |
| Mounting Bracket | BU | Universal for pipe or wall mounting / AISI 304 ss |
| Manuals | M5 | English |
Specifications
Instrument Warranty is subjected to specific Manufacturer.
